Nussbaum 2-Post Lift OTTO18

Nussbaum 2-Post Lift 18,000lb Capacity:

The OTTO 18 is equipped with flexible, space-saving double-jointed arms and an enormous lifting capacity. The OTTO 18 can safely lift vehicles ranging from small passenger cars and light trucks up to large tractor trailers. The dual power unit, with control panel at both columns provides bigger comfort and safety. And thanks to the electronic sync system, there is no rigid top connection, which allows the installation height to be variable.

Ask a Question About this Product
  • Features & Benefits

OTTO15 2-Post Lift Features:

  •  Security and synchronization with the Safety Star Technology
  •  Shut off bar on top
  • No ground connection
  • Double-jointed arms
  • Fast lifting and lowering
  • Low maintenance and almost wear-free cylinder

Tech Specs:

  • Capacity: 18,000 lb
  • Pick up pad height min: 5.5 – 8.5 inch
  • Front arms extension min-max: 0-74.5 inch
  • Rear arm extension min-max: 0-74.5 inch
  • Column height: 107.75 inch
  • Lifting height: 78.75 inch
  • Overall width min: 165.75 inch
  • Drive-through width min: 102.75 inch
  • Total height min: 182.75 – 200.75 inch
  • Power supply (V/ph): 208/230V 1 PH
  • Motor power: 3 hp
